鏈條

型號

節距

寬

滾子

鏈片

小軸

橫向

抗拉

概略

P

W

直徑

高

厚度

直徑

長

節距

強度

重量

i nch

m m

(最小值 )

R(最大值)

H(最大值)

T1

T 2

D(最大值)

F(最大值)

G (最大值)

C

kgf(最小值)

Kg/m

2 5

1/4”

6.35

3.10

3.30

6.02

0.75

0.75

2.31

9.1

11.6

—

357

0.14

2 5-2

1/4”

6.35

3.10

3.30

6.02

0.75

0.75

2.31

15.5

18.0

6.40

714

0.26

3 5

3/8”

9.525

4.68

5.08

9.05

1.25

1.25

3.60

13.2

16.5

—

806

0.33

3 5-2

3/8”

9.525

4.68

5.08

9.05

1.25

1.25

3.60

23.4

26.7

10.10

1612

0.69

3 5-3

3/8”

9.525

4.68

5.08

9.05

1.25

1.25

3.60

33.5

36.8

10.10

2418

1.05

4 1

1/2”

12.70

6.25

7.77

9.91

1.25

1.25

3.60

14.0

16.0

—

684

0.41

4 0

1/2”

12.70

7.85

7.92

12.07

1.50

1.50

3.98

17.8

21.7

—

1418

0.63

4 0-2

1/2”

12.70

7.85

7.92

12.07

1.50

1.50

3.98

32.3

36.2

14.40

2837

1.19

4 0-3

1/2”

12.70

7.85

7.92

12.07

1.50

1.50

3.98

46.7

50.6

14.40

4255

1.77

5 0

5/8”

15.875

9.40

10.16

15.09

2.00

2.00

5.09

21.8

25.9

—

2224

1.01

5 0-2

5/8”

15.875

9.40

10.16

15.09

2.00

2.00

5.09

39.9

44.0

18.10

4449

2.04

5 0-3

5/8”

15.875

9.40

10.16

15.09

2.00

2.00

5.09

57.9

62.0

18.10

6673

3.05

6 0

3/4”

1 9.05

12.57

11.91

1 8.10

2.40

2.40

5.96

26.9

31.5

—

3194

1.44

6 0-2

3/4”

1 9.05

12.57

11.91

1 8.10

2.40

2.40

5.96

49.8

54.4

22.80

6388

3.03

6 0-3

3/4”

1 9.05

12.57

11.91

1 8.10

2.40

2.40

5.96

72.6

77.2

22.80

9582

4.50

8 0

1”

25.40

15.75

15.88

2 4.13

3.20

3.20

7.94

33.5

38.9

—

5673

2.40

8 0-2

1”

25.40

15.75

15.88

2 4.13

3.20

3.20

7.94

62.7

68.1

29.30

11347

5.26

8 0-3

1”

25.40

15.75

15.88

2 4.13

3.20

3.20

7.94

91.9

97.3

29.30

17020

7.80

1 00

1-1/4”

31.75

18.90

19.05

30.17

4.00

4.00

9.54

41.1

47.2

—

8878

3.74

1 00-2

1-1/4”

31.75

18.90

19.05

30.17

4.00

4.00

9.54

77.0

83.1

35.80

17755

7.51

1 00-3

1-1/4”

31.75

18.90

19.05

30.17

4.00

4.00

9.54

113.0

119.1

35.80

26633

11.20

1 20

1-1/2”

38.10

25.22

22.23

36.20

4.80

4.80

11.11

50.8

57.4

—

12755

6.18

1 20-2

1-1/2”

38.10

25.22

22.23

36.20

4.80

4.80

11.11

96.3

102.9

45.40

25510

12.25

1 20-3

1-1/2”

38.10

25.22

22.23

36.20

4.80

4.80

11.11

141.7

148.3

45.40

38265

18.30

1 40

1-3/4”

44.45

25.22

25.40

42.23

5.60

5.60

12.71

54.9

62.3

—

17347

7.49

1 40-2

1-3/4”

44.45

25.22

25.40

42.23

5.60

5.60

12.71

103.6

111.0

48.90

34694

14.83

1 40-3

1-3/4”

44.45

25.22

25.40

42.23

5.60

5.60

12.71

152.4

159.8

48.90

52041

22.20

1 60

2”

50.80

31.55

28.58

48.26

6.40

6.40

14.29

65.5

73.4

—

22755

10.10

1 60-2

2”

50.80

31.55

28.58

48.26

6.40

6.40

14.29

124.2

132.1

58.50

45510

20.04

1 60-3

2”

50.80

31.55

28.58

48.26

6.40

6.40

14.29

182.9

190.8

58.50

68265

30.02

1 80

2-1/4”

57.15

35.48

35.71

54.30

7.10

7.10

17.46

73.9

83.0

—

28673

13.40

1 80-2

2-1/4”

57.15

35.48

35.71

54.30

7.10

7.10

17.46

140.0

149.1

65.84

57347

26.20

1 80-3

2-1/4”

57.15

35.48

35.71

54.30

7.10

7.10

17.46

206.0

215.1

65.84

86020

38.10

2 00

2-1/2”

63.50

37.85

39.68

60.33

8.00

8.00

19.85

80.3

90.5

—

35408

16.50

2 00-2

2-1/2”

63.50

37.85

39.68

60.33

8.00

8.00

19.85

151.9

162.1

71.60

70816

32.70

2 00-3

2-1/2”

63.50

37.85

39.68

60.33

8.00

8.00

19.85

223.5

233.7

71.60

106224

49.05

2 40

3”

76.20

47.35

47.63

72.40

9.50

9.50

23.81

95.5

106.0

—

51020

24.20

2 40-2

3”

76.20

47.35

47.63

72.40

9.50

9.50

23.81

183.4

193.9

87.80

102041

47.80

2 40-3

3”

76.20

47.35

47.63

72.40

9.50

9.50

23.81

271.3

281.8

87.80

153061

71.10
