規格 S tandard No. |
d |
D |
T |
螺栓 Bolt |
|||||
|
D 1 |
孔數 Q ’ty |
孔徑 size |
d1 |
||||||
|
JTW-10 |
1 0.2 |
+0.2 +0.1 |
3 0 |
3 |
0 -0.1 |
20 |
2 |
M 3 |
－ |
|
JTW-12 |
1 2.2 |
+0.2 +0.1 |
4 0 |
3 |
0 -0.1 |
2 8 |
2 |
M 3 |
3 .5 |
|
JTW-13 |
1 3.2 |
+0.2 +0.1 |
40 |
3 |
0 -0.1 |
28 |
2 |
M 3 |
3 .5 |
|
JTW-14 |
1 4.2 |
+0.2 +0.1 |
4 0 |
3 |
0 -0.1 |
2 8 |
2 |
M 3 |
3 .5 |
|
JTW-15 |
1 5.2 |
+0.2 +0.1 |
50 |
3 |
0 -0.1 |
3 5 |
2 |
M 3 |
3 .5 |
|
JTW-16 |
1 6.2 |
+0.2 +0.1 |
5 0 |
3 |
0 -0.1 |
3 5 |
2 |
M 3 |
3 .5 |
|
JTW-16N |
1 6.2 |
+0.2 +0.1 |
50 |
3 |
0 -0.1 |
－ |
－ |
－ |
－ |
|
JTW-18 |
1 8.2 |
+0.2 +0.1 |
5 0 |
3 |
0 -0.1 |
3 5 |
2 |
M 3 |
3 .5 |
|
JTW-20 |
20.2 |
+0.2 +0.1 |
50 |
5 |
0 -0.1 |
3 5 |
2 |
M 5 |
6 |
|
TW-20N |
20.2 |
+0.2 +0.1 |
5 0 |
5 |
0 -0.1 |
－ |
－ |
－ |
－ |
|
JTW-25 |
25.2 |
+0.2 +0.1 |
55 |
5 |
0 -0.1 |
4 0 |
2 |
M 5 |
6 |
|
JTW-25N |
25.2 |
+0.2 +0.1 |
5 5 |
5 |
0 -0.1 |
－ |
－ |
－ |
－ |
|
JTW-30 |
30.2 |
+0.2 +0.1 |
6 0 |
5 |
0 -0.1 |
4 5 |
2 |
M 5 |
6 |
|
JTW-35 |
35.2 |
+0.2 +0.1 |
7 0 |
5 |
0 -0.1 |
5 0 |
2 |
M 5 |
6 |
|
JTW-40 |
40.2 |
+0.2 +0.1 |
8 0 |
7 |
0 -0.1 |
6 0 |
2 |
M 6 |
7 |
|
JTW-45 |
45.3 |
+0.2 +0.1 |
9 0 |
7 |
0 -0.1 |
6 7.5/70 |
2 |
M 6 |
7 |
|
JTW-50 |
50.3 |
+0.3 +0.1 |
1 00 |
8 |
0 -0.1 |
7 5 |
4 |
M 6 |
7 |
|
JTW-55 |
55.3 |
+0.3 +0.1 |
1 10 |
8 |
0 -0.1 |
8 5 |
4 |
M 6 |
7 |
|
JTW-60 |
60.3 |
+0.3 +0.1 |
1 20 |
8 |
0 -0.1 |
9 0 |
4 |
M 8 |
9 |
|
JTW-65 |
65.3 |
+0.3 +0.1 |
1 10 |
8 |
0 -0.1 |
8 5 |
4 |
M 6 |
7 |
|
JTW-70 |
70.3 |
+0.3 +0.1 |
1 30 |
10 |
0 -0.1 |
1 00 |
4 |
M 8 |
9 |
|
JTW-75 |
75.3 |
+0.3 +0.1 |
1 40 |
10 |
0 -0.1 |
1 10 |
4 |
M 6 |
9 |
|
JTW-80 |
80.3 |
+0.3 +0.1 |
1 50 |
10 |
0 -0.1 |
1 20 |
4 |
M 8 |
9 |
|
JTW-90 |
90.5 |
+0.3 +0.1 |
1 70 |
10 |
0 -0.1 |
1 40 |
4 |
M 10 |
1 1 |
|
JTW-100 |
100.5 |
+0.3 +0.1 |
1 90 |
10 |
0 -0.1 |
1 60 |
4 |
M 10 |
1 1 |
|
JTW-120 |
120.5 |
+0.3 +0.1 |
2 00 |
10 |
0 -0.1 |
1 75 |
4 |
M 10 |
1 1 |
